MicroFit MFHLP30986 Replaces the Main Filter MF0059418

MF0059418
MF0059418
Representative product image Product image feedback

MicroFit® UltraGen III MFHLP30986 Pressure Filter | Replaces the Main Filter MF0059418

Brand: MicroFit
Description

The MICROFIT® UltraGen III MFHLP30986 is the MICROFIT® approved replacement to the Main Filter MF0059418. Engineered and manufactured in Great Britain the MFHLP30986

Price Match
$ 2,535.00
3.07 kg
0.002 m³
United Kingdom
8421.99.90
0.64 kg
0.002 m³
Italy
8421.99.90
Shipping Terms

Description

The MICROFIT® UltraGen III MFHLP30986 is the MICROFIT® approved replacement to the Main Filter MF0059418. Engineered and manufactured in Great Britain the MFHLP30986

Specification

StylePressure Filter
MediaGlass Fiber
Efficiency 110µ @ β200
Efficiency 212µ @ β1000
Outer Diameter 78.0 mm
Inner Diameter 43.2 mm
Length 329.0 mm
Δ Collapse Pressure 40 bar
Seal MaterialViton
Temperature Range -25 - +120°C
Default Brand Logo

Same Fit-Form & Function

As the Genuine Main Filter MF0059418

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β200
Efficiency 2 12µ @ β1000
Style Pressure Filter
Outer Diameter 78.0 mm
Inner Diameter 43.2 mm
Length 329.0 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 40 BAR
Seal Viton
Temperature Range -25 - +120°C
