Stauff RP-200-E-20-B/4 Replaces the Stauff RP200E20B
Stauff RP-200-E-20-B/4 Return Filter | Replaces the Stauff RP200E20B
RP-200-E-20-B/4
Stauff
Stauff RP200E20B
Stauff
Stauff RP200E20B
Brand:
Stauff
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 20 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 152 Inner Diameter (mm): 82,3 Length (mm): 423 Sealing: NBR, β ratio >200
Regular price
$ 6,389.00
Unit price
per
Germany
8421.99.90
7.94 kg
0.0099 m³
United Kingdom
8421.99.90
3.9 kg
0.0119 m³
France
8421.99.90
3.6 kg
0.0099 m³
Italy
8421.99.90
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 20 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 152 Inner Diameter (mm): 82,3 Length (mm): 423 Sealing: NBR, β ratio >200Specification
| Style | Return Filter |
| Media | Glass Fiber |
| Efficiency 1 | 20µ @ β200 |
| Efficiency 2 | 22µ @ β1000 |
| Outer Diameter | 152.0 mm |
| Inner Diameter | 83.4 mm |
| Length | 427.0 mm |
| Δ Collapse Pressure | 10 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Stauff Product
Genuine Stauff RP-200-E-20-B/4
Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
